The end of oil? Guess again

Sure, the easy-to-find black gold is getting scarce. But Big Oil has a few cards left to play -- no matter what the cost to the environment or the developing world.

  • more
    • All Share Services

The end of oil? Guess again

Are we “out of gas”? Is it the “end of oil,” as the titles of two recent books suggest? Environmentalists and human rights advocates everywhere might breathe a sigh of relief, if so! Now, finally, we can move on from rapacious, climate-clogging, Nigerian-and-Colombian-slaughtering hydrocarbons to something better. Big Oil is going down! Right?

If only.

Keep in mind that the $2 trillion oil industry is well-practiced at rising miraculously from the dead. In 1879, the light bulb was invented, in a stroke destroying the entire market for oil, which was premised on supplying kerosene lamps. In 1909, the world’s first Big Oil company, Standard Oil, was beheaded. In 1960, OPEC was formed and oil companies were effectively shut out of more than half the world’s known oil reserves. In 1997, the Kyoto Protocol threatened to permanently curb global oil consumption. Now, in 2004, so many people want so much oil that it seems there just isn’t going to be enough. Demand is overtaking supply.

But is it?

True, from the perspective of the Big Oil companies, all the good stuff — the kind of oil that makes itself known by conveniently appearing in puddles at the surface, generously spurting out of the ground under its own pressure, and politely declining multibillion-dollar state interventions for security — is gone. But this, arguably, has been true since the early 1970s, when the flow of oil from stable, homey places like Texas and Oklahoma sputtered out.

Since then, Western oil companies have been successfully drilling for oil in progressively more hostile, unforgiving places, from the deeply frozen tundra of the north slope of Alaska and the densely populated swamps of the Niger delta, to the stormy North Sea and thousands of feet under the shifting waters of the Gulf of Mexico. And each foray has left broken communities and ecosystems in its wake.

Big Oil’s quest to survive in the age of diminishing oil reserves will likely intensify the trend.

Although the big oil companies could easily ramp up their solar and wind power divisions in preparation for the end of oil — for the cost of a single leg of a drilling rig, for instance, oil companies could build a solar-cell manufacturing plant that would make the price of solar power competitive with coal — the evidence suggests they have quite different plans in mind.

Over the next two decades, the U.S. oil industry plans to spend the biggest chunk of its exploration budget hunting for crude not in Alaska, California, and Scotland but in developing countries. Whatever black gold they find will be subject to fewer environmental regulations and will have ready access to cheap, expendable labor, but will be unlikely to uplift the locals. The deadly violence endured by Iraqis, Nigerians and Colombians who have the misfortune to live near Big Oil’s stomping grounds testify to oil exploitation’s dire consequences for those unlucky enough to live near the oil patch. After all, the business of oil extraction in countries as diverse as Algeria, Angola, Congo, Ecuador, Gabon, Iran, Iraq, Kuwait, Libya, Peru, Qatar, Saudi Arabia and Trinidad Tobago has coincided not with increased prosperity but with a sharp downward slide in living standards.

Transforming unreachable “unconventional” fossil fuel resources into exploitable “conventional” reserves using technology and government subsidies is another likely tactic, one that will place a heavy burden on fragile and underprotected ecosystems. Across the bleak landscape of Alberta, Canada, for example, is a huge stretch of sludge called “tar sands.” Back in the 1960s, the technology to mine oil from tar sands, like the technology to extract oil from the Alaska tundra, or the churning North Sea, didn’t exist. These resources were, therefore, untouchable. Slowly, the technology improved, the price of oil went up, and the Canadian government offered generous subsidies. Today, the price of extracting a barrel of oil from tar sands has fallen from around $30 in the 1980s to around $5, and in 2003, the Department of Energy redefined no fewer than 180 billion barrels of tar sands as “conventional oil,” increasing their assessment of the global supply of oil by a whopping 15 percent. Overnight, Canada leapfrogged over Iraq to become the country with the second-biggest oil reserves in the world.

And yet, mining oil from tar sands burns up to a fifth of Canada’s natural gas supply, emits no less than six times more carbon dioxide than producing a barrel of conventional oil, requires six times more fresh water than the oil it renders, and leaves behind vast, festering lakes of wastewater while Canadian farmers shiver and their livestock parch. The acid rain from today’s tar-sands operations alone could destroy Alberta’s forests. And this dirty, wasteful development could go on for decades. Experts say there are 2.5 trillion barrels of oil locked in tar sands, that is, more oil than in all of the world’s conventional reserves. By 2030, Canadian officials expect tar-sands oil to sate no less than 15 percent of the United States’ ravenous appetite for oil.

Plans are already underway to shift consumers from oil to natural gas. All the major oil companies are actually oil and gas companies, and for many, gas reserves are growing while oil reserves are falling. Shell’s CEO recently announced the company’s hope that demand for gas will outshine demand for oil by 2025, making the current era a “window of opportunity” for oil companies to shift their customers from one fossil fuel to the other. Both John Kerry and George W. Bush favor the construction of yet another lengthy pipeline across the Alaska wilderness, this time to deliver natural gas, endlessly mouthing the industry’s mantra, that natural gas is a “clean, environmentally friendly” fuel.

This is a half-truth at best. Methane-rich natural gas is a much more dangerous greenhouse gas than carbon dioxide. Already, about 2.3 percent of the natural gas produced by the industry leaks out of valves, pipes and other infrastructure, unburned. If that proportion makes it up to 3 percent, using natural gas is no better for the atmosphere than burning oil. Supplying consumers with more gas will also require dangerous, wasteful practices such as natural gas liquefaction — that is, burning more fuel in order to cool the gas to negative 260 degrees Fahrenheit, at which point it becomes liquid and thus easier to transport. Keeping the gas pipelines full will exact its pounds of flesh just as effectively as oil, too. All the largest remaining reserves sit under conflict-ridden, densely populated regions in countries such as Nigeria, Angola, Venezuela and Indonesia.

If Big Oil, through these and other tactics, can’t adequately slake Americans’ thirst for cheap energy, U.S. leaders have another plan: Burn more coal. This time, they say, “clean coal” technologies will be employed — that is, the coal will be combusted to make hydrogen gas, the resulting clouds of carbon dioxide stashed away, “sequestered,” never to be heard from again. The technology to do this is nascent and unproven. Worse, one of the least understood, most poorly regulated regions on earth will likely prove the final dumping ground for the excess carbon dioxide: the deep oceans. We may never fully know the damage this might wreak: Compared with deep-sea oil drilling, deep-sea oceanography is woefully underfunded, although many oceanographers say that the uncharted abyss may hold as much biodiversity as tropical rainforests.

All of these developments will cost money and require new generations of technology, of course. Today’s high oil prices and angst over the security of our petroleum supplies can only help, by fattening Big Oil’s coffers and beefing up public support for whatever subsidy oil companies promote as essential to our “energy independence.” If so, our worries over diminishing oil supplies might presage not the “end” of oil but rather the beginning of a renewed assault on the precious resources buried in our planet’s crust.

The new oil

Methane hydrates, locked deep beneath the ocean floor and Alaska permafrost, could be the next great energy source. That is, if they don't blow up in our faces and dangerously accelerate global warming.

  • more
    • All Share Services

The new oil

The biggest single reservoir of carbon on the planet — 10 trillion tons — lies entombed under permafrost and the deepest oceans, locked into mounds of mysterious methane hydrates, bizarre icelike compounds that form when flammable methane gas encounters cold, high-pressure conditions.

Methane hydrates can respond quite violently to perturbations in their temperature-pressure environment. Eight thousand years ago, over a thousand cubic miles of quivering methane hydrate beds exploded when the seas above them got too warm. They slid almost 500 miles off the continental slope into the Norwegian Sea, leaving behind massive craters on the seafloor and setting off gigantic tidal waves that drowned miles of coastline.

Fifteen thousand years ago, climate scientists hypothesize, methane hydrate meltdowns may have unleashed enough heat-sucking methane into the atmosphere to shoot the global temperature up by 10 degrees Celsius, an abrupt finale to the last ice age.

Methane hydrates can be dangerous, drilling them for gas is expensive, and environmentalists are wary of their exploitation. So why, then, is the U.S. Department of Energy paying oil companies and others $50 million to plunge their rotating drills into the seafloor and permafrost in search of the fiery ice?

While scientists quibble over the exact size of the world’s methane hydrate deposits, few question that the overall endowment is, as the Department of Energy puts it, “truly staggering.” Methane hydrates may hold 100 times more gas than all of the world’s conventional natural gas reserves: perhaps even more energy than all of the coal, oil and natural gas found the world over, geologists say.

It isn’t easy to study these strange formations. Most of the world’s methane hydrates lie buried hundreds of feet under the ocean floor. Once liberated from the temperature-pressure matrix that holds them in icy thrall, hydrates rapidly dissociate into invisible methane gas — vast quantities of it.

For most of the last century’s Age of Cheap Oil, methane hydrates have been little more than an academic curiosity. But that’s changing fast. At the end of December 2003, an international consortium including BP, Chevron, and U.S. and Canadian geologists succeeded in capturing what may turn out to be the holy grail of hydrate technology: They transformed hydrates from under northern Canada’s permafrost back into gas and captured the stuff.

“We heated them to 55 degrees Celsius,” explains the U.S. Geological Survey’s Tim Collett, “but you probably only have to go to 12 degrees Celsius … We proved the technology with more or less conventional oil and gas techniques.”

“Now we have to look at the economics,” Collett adds.

Today, with the world’s oil reserves in terminal decline, gas is the new oil, practically as good as black gold itself. According to recently deposed Shell chairman Philip Watts, natural gas, which today provides just 16 percent of the world’s primary energy needs as opposed to oil’s commanding 43 percent, could overtake crude as the world’s primary energy source within a mere two decades.

But in the United States, domestic gas supplies have started to decline. In 1998, the Texas gas industry had to drill 4,000 new wells in order to keep natural gas production steady; the following year, they had to drill 6,400 new wells to do the same. In the Gulf of Mexico, the number of drilling rigs looking for gas shot up by 40 percent between 1996 and 2000, but produced virtually the same amount of gas. The situation in nearby Canada isn’t much better: Between 1998 and 2007, despite the planned drilling of more than 100,000 wells, Canadian natural gas production is expected to essentially remain flat, energy analysts say.

Getting more natural gas from foreign gas fields won’t be possible without cooling the gas to negative 162 degrees Celsius so it can be shipped in liquid form, an expensive, terrorist-attracting activity. Worse, comments natural-gas analyst Julian Darley, “almost all the new country sources are either unstable, potentially unfriendly, or Muslim — or all three.”

Methane hydrates, on the other hand, can be found in the Gulf of Mexico, Canada and Alaska. The challenges of commercial-level production, though, are stiff. Observers call Japanese methane-hydrate drilling efforts “horrifically dangerous.” If a fist-size piece makes its way up the pipe, it emerges at the surface as an explosion of up to 40 gallons of flammable gas. Piercing the hydrates can unleash even greater hazards, as they sometimes act as plugs on gigantic bubbles of volatile gas.

Plus, “when you produce the hydrates, it actually cools itself,” Collett says. “If you depressurize it without adding heat, it becomes colder and colder, so you drive yourself back into the hydrates’ equilibrium range.” As a result, current techniques to extract gas from hydrates are estimated to cost six times more than for conventional oil and gas reserves.

Sounds bad, but in the 1980s it cost 15 times more to extract oil from Canada’s vast stretch of tarry sands than from a conventional oilfield. By 2003, government subsidies and technological advances had transformed “unconventional” tar sands into conventional oil reserves, catapulting Canada’s reserves above those of Iraq and second only to Saudi Arabia’s. Energy ministers and oil companies are betting the same might happen with methane hydrates.

“If the current momentum is sustained,” says the Energy Department’s Tom Mroz, “it is likely that U.S. consumers will see some energy as a result of producing gas from hydrate reservoirs by 2015.” With abundant beds of methane hydrates in its otherwise resource-poor territory, energy-hungry Japan has forked out hundreds of millions to unlock methane hydrate riches, similarly forecasting 2015 as the hydrate-gas start date.

Environmentalists are not keen about the prospect of opening up multiple methane hydrate mines. “We cannot afford to burn more than a small fraction of traditional gas resources, much less mine new frontiers,” complains oceanographer and climate change scientist Jeremy Leggett. “Thinking of burning methane hydrates is like opening a Pandora’s box knowing a murderous and quite probably genocidal genie lurks within it,” he says.

One problem is that “much more methane escapes during the production and processing of natural gas than had previously been realized,” Darley says. Methane is 20 times more powerful a greenhouse gas than carbon dioxide, so a mere 3 percent rate of leakage from ever-lengthening gas pipelines can undermine the environmental benefits of burning it instead of oil. According to the latest available EPA figures, pipelines and wells in the U.S. leaked around 1.5 percent of their methane into the atmosphere in 2000. Worldwide, leaky gas pipelines and other gas infrastructure could be spewing as much as 2.3 percent, according to the International Energy Agency.

Texas A&M University oceanographer Ian MacDonald has spent his career diving under the Gulf of Mexico’s towering oil rigs, studying the orange and white bacterial mats and 6-foot-tall tube worm colonies that feast on yellowed mounds of methane hydrates. He thinks exploiting the giant resource to feed the world’s thirsty machines is a good idea. “The more gas we can use the better, if we have to use fossil fuels,” he says. “If gas hydrate could accomplish that, I would be all for it.”

But a pedestrian matter such as fuel is nothing compared to the grander mysteries of methane hydrates, MacDonald says.

“If it turns out that there is as much carbon in hydrate as we think there is,” MacDonald says, “the discovery with respect to the climate and the carbon cycle is one of those paradigm-shifting things.” Whether or not tomorrow’s industries chug on gas from methane hydrates, “the real mystery of hydrates,” he says, “is that this huge pool of carbon, over geologic time, can’t stay as it is.”

Over the last half century, carbon dioxide, methane and other greenhouse gases have warmed the deep oceans that encase methane hydrates by about three-tenths of a degree, according to the latest figures from the Intergovernmental Panel on Climate Change. If the deep seas warm by 2 degrees Celsius, the depth that hydrates require to remain stable increases from 550 meters to 800 meters, according to the American Association of Petroleum Geologists.

Without a corresponding tidal wave of extra water to hold them in check, the hydrates will transform into silvery bubbles once again, offering up their powerful, heat-trapping methane to the water column and the ever-thickening blanket of gases poaching the planet.
